亚洲欧美激情一区二区 SKFFBSA 205/ QFC参数
| 角接触推力球轴承 for screw drives, cartridge units with flanged housing | |||||||||||
| 主要数据尺寸 | 基本负荷额定值 | 疲劳负荷限值 | 可达到的速度 | 体积 | 型号 | ||||||
| 动态 | 静态 | 预压 | SKF | SNFA | |||||||
| A | B | ||||||||||
| d | D2 | A | C | C0 | Pu | ||||||
| mm | kN | kN | r/min | kg | - | ||||||
 | |||||||||||
| 25 | 80 | 82 | 36,512 | 104 | 3,86 | 4500 | 2250 | 3,5 | FBSA 205/ QFC | BSQU 225 TFT | |
SKFAngular contact thrust ball bearings for screw drivesFBSA 205/ QFC属于超高精密轴承，它是角接触推力球轴承 for screw drives, cartridge units with flanged housing的Angular contact thrust ball bearings for screw drives，内径：25，外径：80，厚度82，SKFFBSA 205/ QFC主要应用于机械设备、等领域。如果您需要购买或者了解更多关于SKFFBSA 205/ QFC的信息， 欢迎拨打订购热线：022-27921004
